Features
Standard Models
Thermostats & Controls
Wireless RF Interface Series
• Heat only, Cool only / 4 wire Heat/Cool
• Standard 2 stage Heat/ 1 Stage Cool Heat Pumps
• Multistage heating and/or cooling equipment
• Made in U.S.A. with domestic and foreign
componets
• Works with most low voltage
thermostats
• Max Operating Range: 50 Feet
RFT
RFT-1 shown with
UT thermostat
RFR
Honeywell Line Voltage Thermostats
• Heat only thermostats
• Accurate temperature control
Features
• 22 Amp resistive for mechanical models
T4398A 1021
Precision Mechanical
TL8230A 1003
Electronic Programmable
• Heat only thermostats
• Accurate temperature control
Features
Standard Models
Standard Models
• 16 Amp resistive for electronic models
• Energy Star compliant.
Electromechanical De-Humidistat
Features
• 50VA@ 24VAC - 240VAC
• 10% - 60% relative humidity range
• 4.4 amp @ 120VAC
• 2.2 amp @ 240VAC
Standard Models
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION VOLTAGE CONNECTION
05235502 RFT-1 RF Thermostat Transmitter
Dim: 4” x 5” x .875”
2-AAA
Batteries 6 Wires
05235602 RFR-5 RF Relay Interface
Dim: 4.5” x 6” x 1.25” 24 VAC R-C-R1
1-2-3-4-5
05235702 RFKit-5 RFT-1 & RFR-5 Package 2-AAA
24 VAC
R-C-R1
1-2-3-4-5
05346702 RFR5002 Wireless relay for low voltage systems.Use with SDRF thermostat. 24 VAC R-C-R1
1-2-3-4-5
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
VOLTAGE DIMENSIONS DESCRIPTION
05033002 T4398A 1021 120-240 2.875”x4.375”x2.00D Precision Electric Heating. SPST, 50-80 O F,
22 Amp @ 120-240V 19 Amp @ 277V
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
VOLTAGE DIMENSIONS DESCRIPTION
05033602 TL8230A 1003 240/208 2.70”x4.90”x.90D Electronic Programmable Line VoltageDPST, 15 Amp, 40-86 OF
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION
05891402 H1D1AA Dehumidistat/Electromechanical
