Low Voltage Programmable Thermostats
Features
• 7 Day, 4 Settings Per Day
• Pre-Programmed or Custom Settings
• Control Accuracy +/- 1
o
F of Setpoint Temp
• Backlit Display, Energy Star Compliant
TH147-P
TH115-A-024T
Standard Models
Standard Models
Features
• 7 Day, 4 Settings Per Day
• Pre-Programmed or Custom Settings
• Control Accuracy +/- 1
o
F of Setpoint Temp
• Backlit Display, Energy Star Compliant
2 Stage Low Voltage Thermostat
Standard Models
Features
• 24V single or 2 stage heat and cool
• Gas, oil, or electric with air conditioning.
• Heat only, Heat only with fan, Cool only.
• Battery only, common wire only, or common wire with battery backup.
• System settings - Heat, Off, Cool, Auto, Emergency Heat.
• Dimensions: 3-9/16” H x 5-13/16” W x 1-1/2” D
TW123
Thermostats & Controls
Features
• 8 tumbler locks
• Imported toTPI specifications
TG Series Thermostat Guards
Standard Models
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION
05234002 TH115-A-024T
Heat Only
Temp Range:40-86
O
F
Dims:4.89”H x 2.79”W x .91”D
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION
05235802
TH147-P
7 Day, 4 Settings per Day, Heating/Cooling, 1 Stage Heat/Cool
Temp Range Heat:41-82
O
F, Cool:59-95
O
F
Dims: 5”W x 3”H x 1”D
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
VOLTAGE
TEMP
RANGE
MAX
AMP
06911102
TW123 /
TH5220D
750MV - 2DV
40-90
o
Heat
50-99
o
Cool
1.0
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
DESCRIPTION
05891202
TG1
Plastic Stat Guard/ 6.25” x 3.625” x 3.25” Opening
05891002
TG1B
Metal Stat Guard/ 5.25” x 4.625” x 3” Opening
05891302
TG2
Plastic Stat Guard/ 5.25” x 4.625” x 3.25” Opening
05891602
TG2B
Metal Stat Guard/ 6.25” x 3.625” x 3.25” Opening
05891102
TG3
Plastic Stat Guard/ 8.125” x 4.625” x 3.625” Opening
05891702
TG3B
Metal Stat Guard/ 6.75” x 4.50” x 3.50” Opening
05236102
TG4
Plastic Stat Guard / 3.50” x 3.937” x 1.75” Opening
05236202
TG5
Plastic Stat Guard / 5” x 3.31” x 1.75” Opening
05236302
TG6
Plastic Stat Guard / 5.75” x 4.625” x 1.75” Opening
