3000 Series Midsized Commercial Fan Forced Wall Heater - Multiple Wattage
Approved for
wall or ceiling
installation
Wattage selectable at time of installation.
Models shipped wired to highest wattage.
Approved for horizontal mounting - right or left discharge.
Fan purge circuit.
Disconnect switch.
Drywall depth embossments on back can.
18 gauge powder coated steel & extruded Aluminum front.
Manual reset thermal limit.
• Steel block fin element.
Propeller style fan blade: 1060 RPM motor; 100 CFM.
Weight 6 lbs.
Rough in dimensions: 9 1/4” Wide x 12 1/8” High x 3 5/8” Deep.
Grill dimensions: 10” Wide x 13 1/8” High.
Features
Standard Models
Accessories
Manufactured in U.S.A.
UPC#
686334
MODEL
SELECTABLE INSTALLATION WATTAGE
MAX
VOLTS
MAX
BTU’s
AMPS
TAMPERPROOF IN-BUILT DOUBLE POLE THERMOSTAT (50º - 90º TEMPERATURE RANGE)
996211
E3055T2DWB
750 or 1500
5120
120
12.5
996228
E3058T2DWB
900 or 1800
6143
120
15.0
996259
F3052T2DWB
1000 or 2000
6826
208
8.3
945691
F30522T2DWB
500 or 750 or 1000 or 1250
7680
208
10.8
or 1500 or 1750 or 2250
996280
H3052T2DWB
750 or 1000 - 1500 or 2000
6826 208 / 240
8.3
945721
H30522T2DWB
500 or 750 or 1000 or 1250
7680
240
9.4
or 1500 or 1750 or 2250
996310
G3052T2DWB
2000
6826
277
7.2
TAMPERPROOF IN-BUILT SINGLE POLE THERMOSTAT (50º - 90º TEMPERATURE RANGE)
996068
E3055TDWB
750 or 1500
5120
120
12.5
996075
E3058TDWB
900 or 1800
6143
120
15.0
996105
F3052TDWB
1000 or 2000
6826
208
8.3
945639
F30522TDWB
500 or 750 or 1000 or 1250
7680
208
10.8
or 1500 or 1750 or 2250
996136
H3052TDWB
750 or 1000 - 1500 or 2000
6826 208 / 240
8.3
945660
H30522TDWB
500 or 750 or 1000 or 1250
7680
240
9.4
or 1500 or 1750 or 2250
996167
G3052TDWB
2000
6826
277
7.2
UPC#
686334
MODEL
DESCRIPTION
996945
305EX8
1” EXTENDER
996938
305EX16
2” EXTENDER
996921
305EX32
4” SURFACE MOUNT FRAME
