CVX Series Radiant Cove Ceiling Heater
Cove Heaters have a subtly contoured concave surface with a saw-tooth profile. The concave parabolic face plate
performs a two-fold function: (1) it focuses the infrared rays and (2) directs the heat downward along cold perimeters
and toward the center of the room. The sawtooth surface design increases the radiating surface area by 45%, thereby
increasing the comfort level of the room faster and insuring more rapid recovery from heat losses.
Furnish and install Electric Cove Heaters where specified. The heaters shall be constructed of .962” thick Aluminum.
The heater surface shall be concave in contour and saw-tooth in profile. The finish shall be of powder coat white finish.
The heaters shall be available in ratings from 450 through 1250 Watts, at 120, 240, 208 and 277 Volts. The heating
element shall be of Nichrome wire, embedded in Magnesium Oxide powder, enclosed and sealed in Aluminum metal
tubing. The heater shall be listed by ETL and the elements shall be supplied with a one year limited warranty.
Product Specifications
Product Description
Accessories & Dimensions
* Order 2 for units up to 72”
Order 3 for units over 72”
Standard Models
Manufactured in U.S.A.
UPC#
686334 MODEL
DESCRIPTION WT.
457927 CVCBX Ceiling Bracket*
1/2 lb.
457866 CVB42X 42” Blank Section
6 lb.
457873 CVB60X 60” Blank Section
8 lb.
457880 CVB84X 84” Blank Section 12 lb.
457912 CVSP Aerosol Touch-up Paint
1 lb.
UPC#
686334 MODEL WATTS BTU's AMPS VOLTS LENGTH WT.
457583 CV4512X 450
1536
4
120
42”
7 lb.
457590 CV45X 450
2
240
457606 CV45YX 450
2.0 208
457613 CV4527X 450
2
277
457620 CV6012X 600
2048
5.0 120
60”
10 lb.
457637 CV60X 600
3
240
457644 CV60YX 600
3
208
457651 CV6027X 600
2
277
457668 CV7512X 750
2560
6
120
72”
13 lb.
457675 CV75X 750
3
240
457682 CV75YX 750
3.6 208
457699 CV7527X 750
3
277
457705 CV9012X 900
3072
8
120
84”
14 lb.
457712 CV90X 900
4
240
457729 CV90YX 900
4
208
457736 CV9027X 900
3
277
457743 CV10012X 1000
3413
8
120
96”
17 lb.
457750 CV100X 1000
4
240
457767 CV100YX 1000
5
208
457774 CV10027X 1000
4
277
457781 CV11012X 1100
3754
9
120
108”
19 lb.
457798 CV110X 1100
5
240
457804 CV110YX 1100
5
208
457811 CV11027X 1100
4.0 277
457828 CV12512X 1250
4266
10
120
120”
21 lb.
457835 CV125X 1250
5
240
457842 CV125YX 1250
6.0 208
457859 CV12527X 1250
5
277
International Models
471190 CV4522Xi
450 1536 2.0 220
42”
7
471206 CV45Xi
1.9 240
471213 CV6022Xi
600 2048 2.7 220
60”
10
471220 CV60Xi
2.5 240
471237 CV7522Xi
750 2560 3.4 220
72”
13
471244 CV75Xi
3.1 240
471251 CV9022Xi
900 3072 4.1 220
84”
14
471268 CV90Xi
3.8 240
471275 CV10022Xi
1000 3413 4.5 220
96”
17
471282 CV100Xi
4.2 240
471299 CV11022Xi
1100 3754 5.0 220
108”
19
471305 CV110Xi
4.6 240
471312 CV12522Xi
1250 4266 5.7 220
120”
21
471329 CV125Xi
5.2 240
