86
Thermostats & Controls
Round - Low Voltage
Features
Does not contain Mercury
Dimensions 3-11/16” diameter
Heat only for 24V heating systems
White color
Temperature range - 50
o
- 90
o
F
Low Voltage Programmable Thermostats
Features
7 Day, 4 Settings Per Day
Pre-Programmed or Custom Settings
Control Accuracy +/- 1
o
F of Setpoint Temp
Backlit Display, Energy Star Compliant
TH147-P
TH115-A-024T
Standard Models
Standard Models
Features
7 Day, 4 Settings Per Day
Pre-Programmed or Custom Settings
Control Accuracy +/- 1
o
F of Setpoint Temp
Backlit Display, Energy Star Compliant
Standard Models
2 Stage Low Voltage Thermostat
Standard Models
Features
24V single or 2 stage heat and cool
Gas, oil, or electric with air conditioning.
Heat only, Heat only with fan, Cool only.
Battery only, common wire only or common wire with battery
backup.
System settings - Heat, Off, Cool, Auto, Emergency Heat.
Temperature range - Heat 40-90
o
F, Cool 50-99
o
F.
Dimensions: 3-9/16” H x 5-13/16” W x 1-1/2” D
TW123
UPC#
686334 MODEL
DESCRIPTION
VOLTAGE
MAX AMP
260008
A6176
Heat/Cool
24 VAC
1.0
UPC#
686334 MODEL
DESCRIPTION
523400 TH115-A-024T
Heat Only
Temp Range:40-86
O
F
Dims:4.89”H x 2.79”W x .91”D
UPC#
686334 MODEL
DESCRIPTION
523585 TH147-P
7 Day, 4 Settings per Day, Heating/Cooling, 1 Stage Heat/Cool
Temp Range Heat:41-82
O
F, Cool:59-95
O
F
Dims: 5”W x 3”H x 1”D,
UPC#
686334
MODEL
VOLTAGE
TEMP
RANGE
MAX
AMP
691116 TW123 / TH5220D 750MV - 2DV
40-90 Heat
50-99 Cool
1.0
