FES & YES Series Heat Wave
TM
Portable Electric & Wall or Ceiling Mounted Salamander
Standard FES Models
FES Series Product Features & Information
• Safety yellow heater enclosure with safety screens on both air intake and
output openings.
• Optional 25’ long SO type cord, ready for plug attachment is available for
each model.
• Long-life finned tubular heating elements.
• Thermostat adjustment 40° to 100° F.
• Magnetic contactor.
• High-limit thermal cutout switch. / Automatic reset.
• Fan only operation.
• 10” wheels.
• 800 CFM: 9, 10, & 15KW units - 1100 CFM-30KW units.
• Made in U.S.A.
Standard YES Models
Wall Mounted Ceiling Mounted
• Wall / ceiling mount included with unit • Made in U.S.A.
• Unit is ready for direct wiring
45 Kilowatt FES Model
• Safety yellow heater enclosure with safety screens on both air intake
and output openings.
• Optional 25’ long SO type cord, ready for plug attachment is
available for each model.
• Long-life finned tubular heating elements.
• Thermostat adjustment 40° to 110° F.
• Two 10” rear wheels and a front locking caster.
• High-limit thermal cutout switch with
manual reset.
• 2200 CFM
• Fan only operation feature
• Made in U.S.A.
THE ELECTRIC
ALTERNATIVE TO
PROPANE AND
KEROSENE SPACE
HEATERS
• Thermostat adjustment 40° to 100° F.
*Plug not included.
AVERAGE MINUTES TO ACHIEVE TEMPERATURE RISE*
BUILDING SIZE:
1000 SQ. FEET
1500 SQ. FEET
2000 SQ. FEET
TEMP RISE
TEMP RISE
TEMP RISE
HEATER:
20
o
F
40
o
F
20
o
F
40
o
F
20
o
F
40
o
F
9/ 10 KW 70 min 140 min 105 min 210 min
---
---
15 KW 47 min 94 min 71 min 142 min 94 min 188 min
30 KW
45 KW
23 min 46 min 35 min 70 min 47 min 94 min
10 min 30 min 20 min 35 min 35 min 40 min
* Based on a 15' ceiling height - lower ceiling height will reduce time required
9 & 10 KW, 240V, 1Phase factory pre-wired model with 10 ft. cable & straight blade range plug.
MFG CATALOG
NUMBER
MFG MODEL
NUMBER KW BTU's VOLTS PH AMPS TEMP
RISE
WT.
(LBS)
LIST
08860110
FES-1520-3A 15 51195 208 3 42 45
o
F 65
1708
08860710
FES-1524-1A 15 51195 240 1 63 45
o
F 69
08860210
FES-1524-3E 15 51195 240 3 36 45
o
F 65
08860310
FES-1548-3E 15 51195 480 3 18 45
o
F 65
08860402
FES-1560-3A 15 51195 600 3 15 45
o
F 65
08860510
FES-3048-3A 30 102390 480 3 36 90
o
F 83
2693
08860602
FES-3060-3A 30 102390 600 3 29 45
o
F 65
2828
MFG CATALOG
NUMBER
MFG MODEL
NUMBER KW BTU's
VOLTS PHASE AMPS TEMP
RISE
WT.
(LBS)
LIST
08744302
FES-0924-1C 9
30717
240
1
38
25
o
F
55
1626
08860010 FES-1024-1CA 10
34130
240
1
42
30
o
F
60
1626
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
KW BTU's VOLTS PHASE AMPS TEMP
RISE
WT.
(LBS)
LIST
08860810 YES-1520-3A 15 51195 208
3
42 45
o
F
60
1626
08861810 YES-1524-1A 15 51195 240
1
63 45
o
F
08860910 YES-1524-3E 15 51195 240
3
36 45
o
F
08861010 YES-1548-3E 15 51195 480
3
18 45
o
F
08861210 YES-3048-3A 30 102390 480
3
36 90
o
F 72
2564
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
KW BTU’s VOLTS PH AMPS TEMP
RISE
WT.
(LBS)
LIST
08722202 FES-4548-3 45 153585 480 3 54.2 70°F 125
4452
04874002 FES-4560-3 45 153585 600 3 44 70
o
F 125
4680
OPTIONAL 25’ POWER CORD
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
LIST
031643002
SO 4/4
325
03164001
SO 6/4
320
OPTIONAL 25' POWER CORD*
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
AMP
RATING
LIST
03164001 SO 6/4
45
320
08805300 SO 4/3
70
278
03164201 SO 12/4
20
154
