TPI Commercial Circulators
These circulators should be used in clean and dry commercial
applications - such as schools, shops, offices or warehouses.
Motor Specifications
• 1-Phase
• 1/4 HP, 1/3 HP on HD Models
• Ball bearing
• Open ventilated
• 120V
• 2 or 3-Speed
• Permanently lubricated
• Permanent split capacitor
• Pull chain switch.
• SJT type 3 conductor, 9’ long cord.
• Coated steel guards with retaining clips.
• Steel hub/spider aluminum paddle blades.
• Pole adjusts center of fan from 43” to 60”.
• Meets OSHA standards.
• 1 Year limited warranty.
• Imported to TPI specifications
Features
Motor, blades, guards, and mount are packed and shipped in a single UPS-able carton.
Commercial Circulator
WALL
MOUNT
PEDESTAL
MOUNT
Standard Models
Note: Stocked models may differ in appearance from photograph
TPI Commercial Oscillating Fans
Standard Models
Commercial wall mount and pedestal fans now available from TPI.
Note: Stocked models may differ in appearance from photograph - sizes are nominal.
Units imported to TPI specifications.
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
SIZE HP TYPE MOUNT TYPE
CFM
AMPS
(HIGH)
WT.
(LBS)
LIST
HIGH MED LOW
08706202 CACU 24-P
24”
1/4 Standard
Pedestal Mount
5400
4900
3900
2.3
63
372
08706402 CACU 24-W
Wall Mount
43
318
08697402 CACU 30-P
30”
Pedestal Mount
6000
5000
4000
2.4
66
411
08706302 CACU 30-W
Wall Mount
46
330
08761702 CACU 30-P-HD 30” 1/3 Heavy Duty Pedestal Mount
6600
5200
4200
3.60
56
478
MFG
CATALOG
NUMBER
MFG
MODEL
NUMBER
SIZE HP TYPE MOUNT
TYPE
CFM
AMPS
WT.
(LBS)
LIST
HIGH MED LOW HIGH MED LOW
08748902 CACU 24-PO
24”
1/4 Standard
Pedestal
Mount
3500 3100 2500 1.45 1.15 1.1
68
436
08749102 CACU 24-WO
Wall Mount
48
372
08749002 CACU 30-PO
30”
Pedestal
Mount
4200 3800 3000 2.0 1.8 1.6
70
457
08749202 CACU 30-WO
Wall Mount
51
404
08761802 CACU 30-PO-HD 30” 1/3 Heavy
Duty
Pedestal
Mount
5600 5000 4500 3.60 3.02 2.94 64
585
