2016 TPI Corporation Electrical Fan & Lights Product Catalog

TPI Industrial Specialty Circulator Heads

Product Specifications

• Pedestal pole adjusts the center of fan from 48” to 67” and bolts to 27” diameter steel dome base with 5

carriage bolts

• I-beam mount & ceiling mount require 1-1/2” or longer pipe nipple for assembly (not supplied)

• Pole mount attaches to 4”, 6”, or 8” with U-bolts (not supplied)

I-BEAM

MOUNT

SUSPENSION

MOUNT

PEDESTAL

OPTIONAL

WHEEL KIT

WALL

MOUNT

CEILING

MOUNT

Standard Models

• No cord-junction box provided for hard wiring

• Steel hub/spider aluminum paddle blades

• Coated steel guards

• Meets OSHA standards

• 1 year limited warranty

• Made in U.S.A. with domestic and foreign components.

Features

Motor Specifications

• All 1 Speed (except 277V which is 2 Speed)

• Totally enclosed, permanently lubricated

• Ball bearing

Standard Models

Note: Wash down rated fan heads have heavy zinc coated guards - Use FDA white coated mounts shown on page 8 for food service applications.

Note: 1-1/2” pipe piece

required for assembly

Note: 1-1/2”

pipe piece

required for

assembly

CIRCULATOR MOUNT

MFG MODEL NUMBER MFG CATALOG NUMBER

WT.

(LBS)

LIST

Pedestal

ACM-P

07961802

192

Wall Mount

ACM-W

07961902

I-Beam Mount

ACM-I

07962002

146

Ceiling Mount

ACM-C

07962102

Suspension Mount

ACM-S

07962202

Pole Mount

ACM-PM

08681802

Optional Wheel Kit

ACM-WK

08681302

GENERAL

DESCRIPTION

MFG

MODEL

NUMBER

MFG

CATALOG

NUMBER

SIZE

CFM

MOTOR

AMPS (HIGH)

WT.

(LBS)

LIST

HIGH LOW HP RPM VOLTS 120v

1 ph

240v

1 ph

277v

1 ph

240v

3 ph

480v

3 ph

Hazardous Location

Class I Group D

Class II Group F & G

Unassembled Head

ACH 24-EX1 08551902 24”

4600

1/4 1725

120 or 240

1-phase

5 2.6 ----

---- ----

1085

ACH 30-EX1 08552002 30”

6500

1177

ACH 24-EX3 08552102 24”

4600

240 or 480

3-phase ----

----

1.4 0.7

1157

ACH 30-EX3 08552202 30”

6500

1267

240V / 480V 3-Phase

Unassembled Head

ACH-24-TE3 08552302 24”

4600

1/4 1725 240 or 480

3-phase ----

----

1.4 0.7

684

ACH-30-TE3 08552402 30”

6500

750

277 Volt

Assembled Head

IHP 24-H-277 08541302 24” 5000 4000

1/3 1125

277

1-phase ----

----

1 ---- ----

526

IHP 30-H-277 08542202 30” 6000 4800

559

Wash down rated

120V / 240V 1-Phase

Assembled Head

IHP 20-H-WD 08721902 20”

4000

1/3 1725 120 or 240

1-phase 4.5 2.2

---- ----

1000

IHP 24-H-WD 08541802 24”

4600

1036

IHP 30-H-WD 08541902 30”

6500

1071
