Product Specifications
CABINET: Shall be constructed of 20 gauge rigid steel with baked on epoxy powder coat paint for du-
rability.
DISCHARGE VANES: Shall extend the entire width of the unit and be adjustable for optimum perfor-
mance of air flow.
BLOWERS: Shall be forward curved centrifugal type, DWDI with corrosion resistance scroll
and wheel.
MOTORS: Shall be heavy duty, PSC, direct drive high efficiency and designed for use with
SCR controllers. Motors shall be permanently lubricated for long life and have thermal over
load protection. Motor shall
have double insulation pro-
tection for quieter operation.
Quick disconnects shall be
supplied to accommodate
easy installation and service
of motor.
SCR SPEED CONTROL-
LER: Supplied on all units
compatible with the motor
with low end adjustment for
air volume control and sav-
ings in power consumption.
ELECTRIC HEAT (OPTION-
AL): Electric heater available
as field installed option. Elec-
tric heater shall be steel sheath
element with helical wound
steel fins for maximum heat
transfer and safety.
Air Curtain with Heater
Module
NOTE: All heating sections
are constructed of totally
enclosed fin tubular ele-
ments for safety and longer
operating life. With heat-
ing section installed, unit
becomes a 24 Volt control
unit and can utilize a low
voltage thermostat for con-
trol of heating.
NOTE: For 72” through
120” units, order multiple
heater modules corre-
sponding to the actual air
curtain models
CF & CFH Series Variable Speed Air Curtains
Manufactured in U.S.A.
SD Series - Setback on Demand Thermostat
FULLY AUTOMATIC: All the savings without any of the hassles of a programmable ther-
mostat. Once installed, everything is automatic. When people are present it automatically
controls to the comfort setting. When they leave, it automatically returns to the economy
setting.
SMART COMFORT: The SD thermostat learns your schedule so you arrive to a comfortable
temperature. Holidays are no problem. When no-one arrives, it automatically returns to the
economy setting.
AUTO-CHANGEOVER: Our Auto-Changeover doesn’t limit your comfort
settings. We incorporate an adjustable deadband to protect your equipment while maintaining
comfort. Factory set at 1 degree, but adjustable from 1-5 degrees.
ONE MODEL WORKS WITH ALMOST ANY LOW VOLTAGE SYSTEM.: The SD ther-
mostat works with low voltage systems up to 4 stages of heat, 4 stages of cool, or any com-
bination up to a total of 4 stages including Heat Pumps.
Patent Pending
EXAMPLE
Use the example shown (left) to order unit with heat section
by specification
Model # Unit Width KW Volts Phase
CFHTR 36 10.0 208
3
|
|
|
|
|
MODEL HEATER
WIDTH KW VOLTS PHASE HEATER
AMPS
MINIMUM CIRCUIT
AMPS
MAXIMUM
FUSE AMPS BTUH 75°C WIRE
AWG
CFHTR
36, 48, or 60 Inch Width
NOTE: 12KW MAXIMUM ON 36” WIDTH UNITS
3
208
3
8.3
10.4
15
10,239
14
240
7.2
9.0
15
14
480
3.6
4.5
15
14
277
1
10.8
13.5
15
14
208
14.4
18.0
20
12
240
12.5
15.6
20
12
5
208
3
13.8
17.25
20
17,075
12
240
12.0
15.0
20
12
480
6.0
7.5
15
14
277
1
18.0
22.5
25
10
208
24.0
30.0
35
8
240
20.8
26.6
30
10
7.5
208
3
20.8
26.0
30
25,597
10
240
18.0
22.5
25
10
480
9.0
11.3
15
14
277
1
27.0
33.8
40
8
208
36.0
45.0
50
6
240
31.2
39.0
45
8
10
208
3
27.7
34.4
40
34,130
8
240
24.0
30.1
35
8
480
12.0
15.0
20
12
277
1
36.1
45.1
50
6
240
41.6
52.0
60
6
12
208
3
33.3
41.6
45
40,956
8
240
28.8
36.0
40
8
480
14.4
18.0
20
12
277
1
43.3
54.1
60
6
15
208
3
41.6
52.0
60
51,195
6
240
36.0
36.0
55
6
480
18.0
18.0
30
10
UPC
686334
SIZE
(in)
MODEL
FT. / MIN.
HI - LOW
NOZZLE
CFM VOLTS RPM
HI - LOW
AMPS
HI - LOW
WATTS
HI - LOW
WT.
(lbs)
STANDARD UNITS: 1/2 HP MODELS - UP TO 10’ HIGH DOORWAYS - WITHOUT HEAT SECTION
671200
36
CF36
3288/455 2672/333
120
1659/620
3.9/3.4
472/154
74
671217
48
CF48
4168/786 4515/766
1606/583
4.4/3.6
519/189
82
671224
60
CF60
4168/764 6544/931
1636/562
4.4/3.8
509/199
90
72
2 EA: CF36 3288/455 5344/666
1659/620
7.8/6.8
944/308 148
96
2 EA: CF48 4168/786 9030/1532
1606/583
8.8/7.2
1038/378 164
108
3 EA: CF36 3288/455 8016/999
1659/620 11.7/10.2 1416/462 222
120
1 EA: CF48 4168/786 9859/1432
1606/583 12.2/10.4 1982/497 230
2 EA:CF36
2672/333
1659/620
HEAVY DUTY UNITS: 3/4 HP MODELS - UP TO 12’ HIGH DOORWAYS - WITHOUT HEAT SECTION
671231
36
CFHD36
3288/1120 2672/819
120
1689/603
4.4/4.3
603/192
77
671248
48
CFHD48
4256/929 4611/906
1662/500
5.9/4.8
586/168
85
671255
60
CFHD60
4256/924 5763/1126
1652/509
5.2/4.4
708/172
93
72 2 EA: CFHD36 3288/1120 5344/1638
1689/603
8.8/8.6
1206/384 154
96 2 EA: CFHD48 4256/929 9222/1812
1662/500 11.8/9.6
1172/336 170
108 3 EA: CFHD36 3288/1120 8016/2457
1689/603 13.2/12.9 1809/576 231
120 1 EA: CFHD48 4256/929 9955/2544
1662/500 14.7/13.4 2981/552 239
2 EA: CFHD36 3288/1120
1689/603
UPC#
686334
MODEL COLOR
TYPE
523646 SDHW1001
White
Hardwire
