80
30 AMP Plug
NEMA #6-30P
20 AMP Plug
NEMA #6-20P
30 AMP Plug
NEMA #6-30P
20 AMP Plug
NEMA #6-20P
30 AMP Plug
NEMA #6-30P
20 AMP Plug
NEMA #6-20P
30 AMP Plug
NEMA #6-30P
20 AMP Plug
NEMA #6-20P
474 Series 240 Volt Dual Heat Fan Forced Portable Heater
2000W & 4000W heat settings
Temperature control thermostat
Manual reset type limit control
6’ long - 3 conductor cord
Width: 16”
Height: 16”
Depth: 8-1/2”
ICH Series 240/208 Volt Construction Site/Utility Fan Forced Portable Heater
680 Series “Bulldog” 240/208 Volt Fan Forced Portable Unit Heater
Swivel base allows unit to be wall, floor, or
ceiling mounted.
Width: 10 5/8”
Height: 12 3/4”
Depth: 10”
Operates on 240V or 208V
Finned steel tubular heating element
Internal manual reset thermal cut-out
6’ long cord with molded plug
Temperature control thermostat with 35°F to 85°F range
10’ air throw - 262 CFM
Width: 13 1/2”
Height: 17 1/2”
Depth: 11 1/2”
* HF684TC UL listed only
Operates on 240V or 208V
Steel tubular heating element
43°F air heat rise
Internal overheat thermostat
Temperature control thermostat
6’ long cordset
5800 Series Garage/Workshop 240/208 Volt Fan Forced Portable Heater
Up to 4800 Watts of heating comfort for
garage or utility room applications
4000 Watts available for smaller areas.
Built in bi-metal double pole
thermostat - 50° to 90° range.
Steel tubular heating element
Wall/Ceiling bracket included
Manual reset standard
Power on and overheat pilot lights
ITEM WIDTH HEIGHT DEPTH
Heater 10.625 11”
9.625”
Bracket
2.5”
10”
14.0”
HF684TC
HF685TC,
HF686TC
UPC#
686334
MODEL WATTS MAX
BTU's VOLTS AMPS PHASE WT.
450874 ICH-240C 4000 / 3000 13648 240 / 208 16.7 / 14.4 1 15 lbs.
UPC#
686334 MODEL WATTS
MAX
BTU's VOLTS PHASE AMPS TEMP
RISE WT.
446280
*
HF684TC 4000/3000 13652/10239 240/208 1 16.7/14.5 48
o
F 20 lbs
446297 HF685TC 4800/3600 16384/12288 240/208 1 20.0/17.4 58
o
F 20 lbs.
446303 HF686TC 5600/4200 19107/14330 240/208 1 23.4/20.2 75
o
F 20 lbs.
683500 A1560 OPTIONAL WALL CEILING BRACKET FOR HF680 & ICH 240c SERIES
HEATERS
UPC#
686334 MODEL WATTS MAX
BTU's VOLTS AMPS PHASE WT.
446181 H474 TMC 2000 / 4000 13652 240 8.3 / 16.6 1 20 lbs.
UPC#
686334 MODEL WATTS MAX
BTU's VOLTS AMPS PHASE PLUG
TYPE
WT.
(LBS)
503402 HF5840TC 4000/3000 13652
240 / 208
16.6 / 14.4
1
20 Amp
17
503396 HF5848TC 4800/3600 15086
20 / 17.3
30 Amp
