Note: 1/3 and 1/4
HP fans come with 3
paddle blades.
WALL
MOUNT
I-BEAM
MOUNT
SUSPENSION
MOUNT
CEILING
MOUNT
OPTIONAL
WHEEL KIT
• 2-Speed
• 1-Phase, 120V
• Ball bearing
• Frame size: 48
• Totally enclosed
• Permanent split capacitor
• Permanently lubricated
• 1/2” Shaft
• Pedestal pole adjusts the center
of the fan from 48 to 67 inches.
• Pedestal steel dome base is 27” in
diameter and has 5 carriage bolts.
• Easy access hinged guard
• 18” drop down, 2-Speed switch
• Cord options are shown below
• Steel hub/spider aluminum paddle blades
• Coated steel guards
• Meets OSHA standards
• Made in U.S.A. with domestic and foreign components.
Standard Models
Motor Specifications
Product Specifications
TPI Industrial Mounts
DIMENSIONS
24” 27” Diameter x 14.5” Depth
30” 33.5” Diameter x 14.5” Depth
Accessories
Closed (Front)
Open (Front)
Note: 1-1/2” pipe piece
required for assembly
Note: 1-1/2” pipe
piece required for
assembly
TPI Industrial Unassembled Maximum Duty Circulators
Features
Note: Motor, blades, guard, and mount are packed and shipped in a single UPS-able carton.
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
COLOR
DESCRIPTION
WT.
(LBS)
LIST
08747202
RS 06-EC
Yellow
6’ Extension cord used with drop down power switch
1
23
08747302
RS 09-EC
Yellow
9’ Extension cord used with drop down power switch
1.5
25
08747402
RS 12-EC
Yellow
12’ Extension cord used with drop down power switch
2
27
08747502
SCK-12
----
12’ Safety cable with clamps
.5
25
08747702
R2-MOT
Gray
1/3 HP motor with drop down remote switch
1
187
08747802
R3-MOT
Gray
1/4 HP motor with drop down remote switch
1
182
FAN TYPE
HIGH PERFORMANCE
MAX
AMPS
STANDARD INDUSTRIAL
MAX
AMPS
MOTOR
HP
1/3
1/4
SPEEDS
2
2
CFM / RPM
24”
5000 / 4000
1100 / 800
2.8
4500 / 3600
1100 / 800
2.5
30”
6000 / 4800
1100 / 800
3.0
5400 / 4300
1100 / 800
2.7
COLOR
GRAY
GRAY
POLE ADJUSTMENT
52” to 78”
52” to 78”
WARRANTY
3 YEARS
1 YEAR
SIZE
TYPE of MOUNT MFG CATALOG
NUMBER
MFG MODEL
NUMBER
WT.
(LBS)
LIST
MFG CATALOG
NUMBER
MFG MODEL
NUMBER
WT.
(LBS)
LIST
24”
Pedestal Mount
08745202
UHP 24-PJR 75
726
08746202
ACU 24-PJR 75
571
Wall Mount
08745402
UHP 24-WJR 45
613
08746402
ACU 24-WJR 45
495
I-Beam Mount
08745602
UHP 24-IJR
50
680
08746602
ACU 24-IJR 50
561
Ceiling Mount
08745802
UHP 24-CJR 45
621
08746802
ACU 24-CJR 45
503
Suspension Mount
08746002
UHP 24-SJR 43
608
08747002
ACU 24-SJR 43
488
30”
Pedestal Mount
08745302
UHP 30-PJR 78
743
08746302
ACU 30-PJR 78
582
Wall Mount
08745502
UHP 30-WJR 48
633
08746502
ACU 30-WJR 48
508
I-Beam Mount
08745702
UHP 30-IJR
53
698
08746702
ACU 30-IJR 53
575
Ceiling Mount
08745902
UHP 30-CJR 48
640
08746902
ACU 30-CJR 48
515
Suspension Mount
08746102
UHP 30-SJR 46
626
08747102
ACU 30-SJR 46
503
