Electric Infrared Heating Controls
Snow & Ice Detectors
Variable Controllers
APS-3C
CIT-1
Main control unit for Automatic Snow & Ice Control Systems.
By sensing both temperature and moisture the system activates and melts any
snow & ice accumulations until conditions subside.
NEMA 3R Enclosure is UL Listed and houses timers and switching electronics
to operate the system.
Capability to monitor up to 6 sensors (CIT-1).
Unit can be manually activated and can be controlled and monitored from an
optional remote switch (Model RCU-).
Positioned above ground to maximize the sensors capability.
Detects falling or blowing of precipitation such as snow when the
temperature is below 38° F.
Most common sensor device.
Note: Any snow & ice control system should be used with the correct sized control panel (with contactors & fusing) as supplied by factory or
your electrical contractor. Also, the APS-3C requires a control device (RCU-1, CIT-1, SIT-6E) in order to operate properly.
VHC-15
18D-2-80CF ENC.
VHC-32
30-Amp or 80-Amp Enclosed
Manufactured in U.S.A.
Manufactured in U.S.A.
Manufactured in U.S.A.
Manufactured in U.S.A.
Solid state variable device controls
heat loads up to 15-Amps.
208/240Volt “In-Line” Controller.
Built in On/Off knob switch with
positive “off” & surface plate
included.
Designed for a 2” x 4” electrical
wall box mounting (not supplied).
Must be mounted in a protected
area.
Can only operate Fostoria Quartz
Tube Infrared Heaters.
SCR Voltage Controller - 80 Amp MAX.
Includes (1) 24-volt Potentiometer (3” square)
to control the heat output.
Only operates Quartz Lamps at 240 or
208-Volts, single phase only.
Potentiometer can be mounted outside, but the
SCR must be located in a protected area.
Factory wired with millisecond fuses included.
Solid State phase angle variable
“Triac” knob controller adjusts
heat settings from 10-100% with
heat loads up to 15.4-Amps.
208/240 VAC single-phase, single
stage controller, 3200 Watt max.
Positive “Off” & built-in On/Off
Rocker switch lights “red” during
operation.
NEMA1Aluminumenclosure with
stainless steel face plate designed
for wall mounting or suitable for
semi-recessed applications.
Must be mounted in a protected
area.
Can either operate Quartz Lamps
or Quartz Tube Infrared Heaters.
Note: Installer to provide overload protection for all infrared heaters.
Contactor Enclosures
Economical load handling / switch device, ideal for use with other control equipment.
NEMA 1 Enclosures.
Load rating up to 600V Max., 3-Pole.
Magnetic contactor.
FEC-30-120
Manufactured in U.S.A.
UPC#
686334
Model
Description
Dimension (In.)
Wt.
Depth
Width
Height
319614
APS-3C
Snow / Ice Control Switch
6.56
11.5
9.25
8 lbs.
319761
CIT-1
General Purpose Snow Sensor
3.25
3.25
4.13
1 lb.
UPC
Model
Description
Dimension (In.)
Wt.
686334
Depth Width Height
485357
VHC-32
Variable Heat Controller 208/240-Volt; 15.4 Amp
3
5
5 3 lbs.
445948
VHC-15
Variable Heat Controller; 208/240-Volt; 15 Amp
3
5
5 3 lbs.
445634 18D-2-30CF (Open)
SCR Controller - 26 Amp MAX; No Enclosure
6
6
9 11 lbs.
445641 18D-2-30CF (Enclosed) SCR Controller - 26 Amp MAX; Enclosure Included 8
10
12 15 lbs.
445658 18D-2-80CF (Enclosed) SCR Controller - 80 Amp MAX; Enclosure Included 8
12
14 29 lbs.
UPC
686334
Model
Contactor
Amps
Coil
Voltage
Cabinet Size (In.)
Wt.
(LBS.)
Depth Width Height
440851 FEC-30-120
30
120
5
6
10
5
440868 FEC-30-240
208/240
440875 FEC-60-120
60
120
440882 FEC-60-240
208/240
