Electric Infrared Heating Elements
Clear & Red Quartz Lamps
Quartz Tubes
Metal Sheath Elements
Notes: Life expectancy of all heating elements - 5,000 hours (4yr. Pro-rated Warranty).
All heating elements operate at 50 / 60 Hertz.
3/8” Diameter clear or red quartz envelope.
Coiled tungsten filament; sealed porcelain end caps; halogen gas filled.
Model Suffix: 630 = Horizontal Burning “Clear”; 631 = Vertical OR Horizontal Burning “Clear”; = Horizontal Burning “Red”
Note:
Inner reflector shipped with replacement Metal Sheath Elements.
*3/8” Diameter
5/8” Diameter frosted quartz envelope
Nickel-Chromium
alloy
coiled
element with porcelain end caps and
pigtailed termination
Color temperature emitted: approx.
1800° F (bright orange glow)
• Approximately 60% radiant efficiency
Fast heat-up/cool-down
Moisture resistance: High
Mechanical ruggedness: Good
Notes: Life expectancy of all heating elements - 5,000 hours.
All heating elements operate at 50 / 60 Hertz.
Notes: Life expectancy of all heating elements - 5,000 hours.
All heating elements operate at 50 / 60 Hertz.
Color temperature emitted: approx. 4100° F (high brightness).
Approximately 96% radiant efficiency.
Excellent resistance to thermal shock.
0.430” Diameter
Incoloy metal
sheath envelope
Nickel-
Chromium alloy
coiled element
imbedded in
Magnesium
Oxide insulating
powder
Color
temperature
emitted: approx.
1600° F (dull
orange glow)
Approximately
50% radiant
efficiency
Slowest heat-up/
cool-down
Moisture
resistance:
Lowest
Mechanical
ruggedness:
Highest
UPC Item # Watts Volts Length (in.)
Fits
UPC Item # Watts Volts Length (in.)
Fits
686334
Overall Heated Model
686334
Overall Heated Model
440059 630-05129 500 120 8-11/16 5 MM-13A 440363 631-25489 2500 480 28-11/16 25 342, 343 or
MM-33A
442770 630-10209 1000 208 13-11/16 10 MM-18A 440684 631-25609
600
444118 630-10249
240
----
----
----
----
41-11/16 38 462, 463 or
MM-46A
440165 630-16209
1600
208
19-11/16 16 222, 223 or
MM-24A
----
----
----
----
440172 630-16249
240
440677 630-36489 3650 480
440998 631-16249
240
446235 630-38579 3800 600
440189 630-16279
277
444132 631-38579 3800 600
481731 630-16489
480
RED QUARTZ LAMPS
481748 630-25209
2500
208
28-11/16 25 342, 343 or
MM-33A
481755 630-25249
240
446150 632-1620 1600 208 19-11/16 16 222/223
481762 630-25279
277
446167 632-1624 1600 240 19-11/16 16 or RPH
440547 630-25489
480
446228 632-2548 2500 480 28-11/16 25 342 or 343
UPC#
686334 MODEL WATTS VOLTS LENGTH (in)
Replacement Heating Element
Overall Heated
Fits “CH-Models”
Fits “FHK Models”
445870 641-37211 1800 120
23-1/16 18
CH-212-1A
FHK-212-1CA
445832 641-35661
2000
208
CH-220-1A, CH-620-3A
FHK 2.0 & 6.0 KW
Models
445795 641-35611
240
CH-224-1A, CH-624-3A
445849 641-36051
277
CH-277-1A, CH-627-3A
445801 641-35621
480
CH-248-1A, CH-648-3A
445887 641-50011
600
CH-257-1A, CH-657-3A
445856 641-36061
4500
208
44-7/16 39
CH-420-1A, CH-1320-3A, CH-2720-3B
FHK 4.5 & 13.5 KW
Models
445818 641-35631
240
CH-424-1A, CH-1324-3A, CH-2724-3B
445863 641-36071
277
CH-427-1A, CH-1327-3A
446174 641-35641
480
CH-448-1A, CH-1348-3A, CH-2748-3B
445894 641-50021
600
CH-457-1A, CH-1357-3A, CH-2757-3B
UPC#
686334 MODEL WATTS VOLTS
LENGTH (in)
Replacement Heating Element
Overall
Heated
Fits “CH-Models” Only
445788 641-70321 1800
120
24-1/16
18
CH-212-1C
445702 641-70241
2000
208
CH-220-1C, CH-620-3C
445719 641-70251
240
CH-224-1C, CH624-3C
445726 641-70261
277
CH-227-1C, CH-627-3C
445733 641-70271
480
CH-248-1C, CH-648-3C
445771 641-70281
600
CH-257-1C, CH-657-3C
445597 641-70001
4500
208
45-7/16
39
CH-420-1C, CH-1320-3B, CH-2720-3C
445603 641-70011
240
CH-424-1C, CH-1320-3B, CH-2720-3C
445610 641-70021
277
CH-427-1C, CH-1327-3B
445627 641-70031
480
CH-448-1C, CH-1348-3B, CH-2748-3C
445665 641-70041
600
CH-457-1C, CH-1357-3B, CH-2757-3C
UPC
686334
Item #
Watts
Volts
Length (in.)
Fits
Overall
Heated Model
443234
671-3784
1500
120
39-11/16 34-3/16
OCH-46
441810
671-5061
2000
208
39-11/16 34-3/16
441803
671-3785
2000
240
39-11/16 34-3/16
441933
671-5018
2000
277
39-11/16 34-3/16
441667
671-5060
3000
208
50-11/16 45-3/16
OCH-57
441476
671-3786
3000
240
50-11/16 45-3/16
441940
671-5059
3000
277
50-11/16 45-3/16
441957
671-5058
2250
480
50-11/16 45-3/16
440356
671-3454
450
120
12-15/16 8-7/16 FFH-912B
440080 671-3492*
550
120
19-1/2
16
FFH-512A
446242
671-5056
1000
120
18-5/16 14-7/16 CH-2212-1C
446259
671-5057
1425
240
27-5/16 23-7/16 CH-6424-1C
